Jingmu Industrial Camera HDMI Real-Time Output Global Exposure High Frame Rate Ultra-Clear Image Quality AI Algorithm

Jingmu Industrial Camera HDMI Real-Time Output Global Exposure High Frame Rate Ultra-Clear Image Quality AI Algorithm

JM-HDC-S36M2M
It is suitable for scenarios that require HDMI to capture high-definition video , such as online video conferencing, electronic magnifiers, drones, automated machine vision, and industrial robots.

Consult

Features
Technical Indicators
Overall Dimension

1. Supports H.265 and H.264 encoding, ultra-low bit rate and high-definition image quality. 2. Supports HDMI 1080P60FPS high-definition video output and up to 4K30fps output. 3. Support 1920 x1 080 @ 30 frames and 1080P @ 60 frames with low latency encoding transmission. 4. Support black and white , full color, day and night automatic switching modes. 5. Support two-way voice intercom. 6. The network supports RTSP, ONVIF, GB28181 , MQTT, and WebRtc protocols. 7. Support remote monitoring via mobile phone and PC , open secondary development SDK. 8. Support DC6~24VDC or POE power supply. 9. Support USB typeC 5V power supply.
Model HDC-S36M2M Master SSC8836Q-H, NPU supports 0.5TOPS computing power Image sensor 1/2.7 " 2 - megapixel HD low-light CMOS SONY IMX307 Video Processing Support H.264/H.265 encoding, bit rate 0.1M~8Mpbs adjustable, 1~60 frames/second adjustable Image Output Main stream: 1920 x 1 080 , 1280 * 720 Sub-stream: D1, VGA, 640×360 Audio Processing G.711/ACC encoding, supports two-way voice intercom HDMI interface HDMI supports 1080P60 and up to 4K30 frames Business Functions Support OSD overlay , support AI algorithm customization , support UI menu customization Reset button interface Support 1 hardware reset interface USB interface 2 USB ports, support WIFI/4G expansion, customizable UVC function Network Protocol Support TCP/IP, IPV4 , RTSP, HTTP, DHCP, NTP, RTMP , MQTT, WebRtc Remote Monitoring Supports mobile phone and PC remote monitoring, and supports open multi-platform P2P/WebRtc SDK docking Network interface 1 RJ45 network interface, 10/100M adaptive, lightning protection and anti-static design Audio Interface Support 1 MIC input, 1 LINE_OUT Serial Port 2 TTL serial ports TF card interface 1 TF card interface, maximum support 256G Operating temperature -20 ~ 70 ℃ Operating voltage DC 6V-24V Size 50mm*52mm*50mm

Model	HDC-S36M2M
Master	SSC8836Q-H, NPU supports 0.5TOPS computing power
Image sensor	1/2.7 " 2 - megapixel HD low-light CMOS SONY IMX307
Video Processing	Support H.264/H.265 encoding, bit rate 0.1M~8Mpbs adjustable, 1~60 frames/second adjustable
Image Output	Main stream: 1920 x 1 080 , 1280 * 720
Image Output	Sub-stream: D1, VGA, 640×360
Audio Processing	G.711/ACC encoding, supports two-way voice intercom
HDMI interface	HDMI supports 1080P60 and up to 4K30 frames
Business Functions	Support OSD overlay , support AI algorithm customization , support UI menu customization
Reset button interface	Support 1 hardware reset interface
USB interface	2 USB ports, support WIFI/4G expansion, customizable UVC function
Network Protocol	Support TCP/IP, IPV4 , RTSP, HTTP, DHCP, NTP, RTMP , MQTT, WebRtc
Remote Monitoring	Supports mobile phone and PC remote monitoring, and supports open multi-platform P2P/WebRtc SDK docking
Network interface	1 RJ45 network interface, 10/100M adaptive, lightning protection and anti-static design
Audio Interface	Support 1 MIC input, 1 LINE_OUT
Serial Port	2 TTL serial ports
TF card interface	1 TF card interface, maximum support 256G
Operating temperature	-20 ~ 70 ℃
Operating voltage	DC 6V-24V
Size	50mm52mm50mm
